Volume: 18 Issue: 4 August 2020


Luschka Duct Leak: An Unexpected Cause of Choleperitoneum After Liver Transplant

The anatomic variabilities in ducts of Luschka put patients at risk during hepatobiliary surgery. Clinically relevant bile leakage is the cause of 0.4% to 1.2% of complications of cholecystectomies, with almost one-third of complications caused by an inadvertent injury to the duct of Luschka. However, bile leakage from a duct of Luschka after liver transplant is rare, and only one previously published report has been found. Here, we report a case of a 67-year-old male patient who underwent liver transplant for cirrhosis due to hepatitis C virus infection. After transplant, the patient had a choleperitoneum caused by bile leakage from a duct of Luschka. The donor surgery had been performed by surgeons from another institution, and they had also performed the previous cholecystectomy. Fifteen days after surgery, a cholangiography showed bile leakage near the anastomosis. A new intervention was decided. After confirmation of the integrity of the anastomosis, methylene blue was injected through the Kehr’s tube, which escaped from a duct of Luschka. The duct was closed, and an intraoperative cholan-giography confirmed that the biliary tree was intact. After this intervention, a new bile leakage was observed, resulting in an endoscopic retrograde cholangiopancreatography scan and sphincterotomy. The Kehr’s tube was kept open until leak resolution. Although unusual after liver transplant, this com-plication should be considered in cases of bile leakage. The ducts of Luschka are difficult to see during cholecystectomy in the graft due to perivesicular edema.

Key words : Bile leakage, Cholecystectomy, Surgical complication


The duct of Luschka was first described by Von Luschka, professor of anatomy in 1863. These ducts are small, accessory bile ducts (1-2 mm in diameter) that originate mainly in the right hepatic lobe, which is located close to the gallbladder bed. The ducts of Luschka are usually found within the connective tissue, most commonly in the center of the gallbladder bed, but they have also been described in the lateral peritoneal reflection. Less often, they are found passing directly into the wall of the gallbladder.

This accessory duct has a variable drainage course and may drain directly into the right hepatic duct, the common hepatic, the gallbladder, or, in rare cases, into the cystic duct. A recent systematic review about the anatomy of bile ducts showed that 69% of subvesical bile ducts originated from the right lobe, with drainage into the right lobe occurring in 40%, whereas drainage into the gallbladder was the most common site of final drainage (48%).1

Knowledge of the anatomy of the biliary tree, with its well-known tendency for structural variations, is important for surgeons who must perform procedures in the right upper quadrant. Anatomic variations can put the biliary tree at risk during hepatobiliary surgery. In the era of laparoscopic cholecystectomy, the ducts of Luschka have gained increased clinical recognition.

Recent studies have suggested that clinically relevant bile leakage is the cause of 0.4% to 1.2% of complications of laparoscopic cholecystectomies, with about 27% of clinically relevant bile leaks caused by an inadvertent injury to a duct of Luschka.1 However, a duct of Luschka injury after liver transplant is rare. In our experience of 950 liver transplants, only 1 pa-tient had a clinically relevant bile leakage from a duct of Luschka (0.001%). To the best of our knowledge, only 1 previous case report of this complication after liver transplant has been published.2

Case Report

A 67-year-old male patient underwent liver transplant for cirrhosis caused by hepatitis C virus infection. Donor and recipient selection had been conducted by the Spanish National Transplant Organization, an institution that is part of the Spanish Ministry of Health. The recipient was assigned an organ from an anonymous deceased donor. Our case patient had donor surgery performed by surgeons from another institution, who also had performed the cholecystectomy after liver graft removal.

At presentation, we performed a choledocho-choledochal termino-terminal anastomosis and used a Kehr’s tube placed at the receptor common bile duct for tutoring anastomosis. An abdominal drain was placed behind the anastomosis. We observed bile outflow though the abdominal drain on day 7 after surgery. A cholangiography was performed, which was normal. On day 15 after surgery, the patient expressed abdominal pain, and increased bile output through the drainage was observed.

A new cholangiography was performed, and contrast extravasation was shown around the bile anastomosis. It was decided to return the patient to the operating room and search for leakage at the anastomosis site. The anastomosis was intact; however, after methylene blue was injected through the Kehr’s tube, the fluid escaped from a duct of Luschka in the gallbladder fossa (Figure 1). The duct was closed, and an intraoperative cholangiogram was obtained to confirm that the biliary tree was intact, demonstrating duct of Luschka closure.

During the postoperative period, bile content appeared again in the drainage. A repeat cholan-giography showed persistence of bile leakage in an aberrant duct in the right hepatic lobe (Figure 2). The patient showed a good clinical condition; therefore, we opted to perform an endoscopic retrograde cholangiopancreatography (ERCP) and sphinc-terotomy. The T-tube was kept open until bile leakage resolution. The patient had a satisfactory course after this procedure; therefore, no other interventions were required. A third cholangiography was performed through the T-tube 8 weeks after reintervention. Because no more bile leakage was shown, the T-tube was removed.


The visualization of an accessory hepatic duct in the donor gallbladder bed after liver transplant is usually difficult because the donor cholecystectomy is completed after extensive ischemic and reper-fusion injury. There is usually extensive edema in the gallbladder wall. The dissection should be performed close to the serosal lining of the gallbladder, preserving the areolar tissue in the gallbladder bed. Any suspicious structures communicating with the gallbladder wall should be specifically ligated to prevent this unusual complication.

We usually perform cholecystectomy after graft implantation, that is, after all anastomoses have been completed. In this patient, the donor surgery had been performed by surgeons at another institution, who had performed the cholecystectomy after liver graft removal and before implantation. We suggest that the cholecystectomy be performed after graft implant.

Injury to the duct of Luschka can cause a cho-leperitoneum, biloma, or a subphrenic or subhepatic intra-abdominal abscess. Clinical manifestations of this complication can be mild, with nonspecific symptoms or abdominal pain with or without fever and symptoms of local or general sepsis. High bilirubin levels are uncommon in these patients.3

Numerous diagnostic methods have been used to detect these injuries. These include abdominal ultra-sonography and computed tomography, magnetic resonance cholangiography, ERCP, percutaneous transhepatic cholangiography, and hepatobiliary iminodiacetic acid scan.

Management of this complication depends on the patient’s clinical condition. Developments in endo-scopic management could allow many patients to have endoscopic procedures, thus avoiding surgical intervention.

A recent study of 42 patients who developed bile leakage after liver transplant showed that ERCP is an effective and safe therapeutic modality for bile leakage after liver transplant. This test should be considered as an initial therapeutic modality in liver transplant recipients.4

Sendino and associates analyzed 80 patients with bile leak after liver transplant. Forty-seven patients (59%) underwent ERCP with plastic stent placement (with or without sphincterotomy), and 33 patients (41%) underwent sphincterotomy alone. Complete resolution was obtained in 94% of patients in the stent group versus only 58% of patients in the sphincterotomy group. Percutaneous transhepatic therapy and surgery were required in 4% and 6% in the stent group versus 12% and 42% in the sphincterotomy group, respectively. The only predictive factor of bile leak resolution was stent placement; therefore, the group concluded that ERCP with plastic stent placement is highly successful and more effective than sphincterotomy alone for bile leak treatment in liver transplant.5

Another work analyzed the optimal time to perform an ERCP after bile leak. The overall success rates and adverse events after ERCP were not dependent on time between the procedure and the discovery of the bile leak. This suggests that ERCP in these patients can usually be performed in an elective rather than in an urgent manner.6 Percutaneous treatment is other option. In the case of leaks and fistulas, bile diversion with drainage is usually attempted to seal the fistulous tract.7

In a recent study that evaluated risk factors and outcomes of bile leak after liver transplant, the incidence of postoperative bile leak was 2.7% (n = 16). Sites of bile leak were identified as duct-to-duct anastomosis (n = 4), cholangiojejunostomy anastomosis (n = 2), and cut surface of the remnant liver (n = 1). However, the site of bile leak was not identified in 9 patients who received conservative management and who showed no obvious site of leakage with ERCP examination. No leaks from the ducts of Luschka were identified. Ten patients (65.5%) were treated with conservative management, and 6 patients ultimately required laparotomy. No differences in 1-year patient survival rate were shown between these 2 groups of patients; however, 2-year patient survival rate was significantly lower in those who had bile leaks.8


Although this complication is unusual after liver transplant, duct of Luschka leakage should be considered in cases of bile leakage. The ducts of Luschka are difficult to see during cholecystectomy in the graft due to perivesicular edema. Management of this complication depends on the patient’s clinical condition.


  1. Schnelldorfer T, Sarr MG, Adams DB. What is the duct of Luschka?--A systematic review. J Gastrointest Surg. 2012;16(3):656-662.
    CrossRef - PubMed
  2. Albishri SH, Issa S, Kneteman NM, Shapiro AM. Bile leak from duct of Luschka after liver transplantation. Transplantation. 2001;72(2):338-340.
    CrossRef - PubMed
  3. Ramia JM, Muffak K, Mansilla A, Villar J, Garrote D, Ferron JA. Postlaparoscopic cholecystectomy bile leak secondary to an accessory duct of Luschka. JSLS. 2005;9(2):216-217.
  4. Oh DW, Lee SK, Song TJ, et al. Endoscopic management of bile leakage after liver transplantation. Gut Liver. 2015;9(3):417-423.
    CrossRef - PubMed
  5. Sendino O, Fernández-Simon A, Law R, et al. Endoscopic management of bile leaks after liver transplantation: An analysis of two high-volume transplant centers. United European Gastroenterol J. 2017;6(1):89-96.
    CrossRef - PubMed
  6. Adler DG, Papachristou GI, Taylor LJ, et al. Clinical outcomes in patients with bile leaks treated via ERCP with regard to the timing of ERCP. A large multicenter study. Gastrointest Endosc. 2017;85(4):766-772.
    CrossRef - PubMed
  7. Krokidis M, Orgera G, Rossi M, Matteoli M, Hatzidakis A. Interventional radiology in the management of benign biliary stenoses, biliary leaks and fistulas: a pictorial review. Insights Imaging. 2012;4(1):77-84.
    CrossRef - PubMed
  8. Fang C, Yan S, Zheng S. Bile leakage after liver transplantation. Open Med. 2017;12(1):424-429.
    CrossRef - PubMed

Volume : 18
Issue : 4
Pages : 526 - 528
DOI : 10.6002/ect.2018.0348

PDF VIEW [630] KB.

From Division of Hepatobiliary Surgery and Liver Transplantation, Department of Surgery, Ramón y Cajal University Hospital, Madrid, Spain
Acknowledgements: The authors have no sources of funding for this study and have no conflicts of interest to declare.
Corresponding author: Alberto Vilar Tabanera, Calle Talia 2 b Madrid, Spain 28022
Phone: +34 649397822
