Vanishing Middle Bronchus in Bilateral Lung Transplant After Ex Vivo Lung Perfusion

Lung transplant has become the mainstay of therapy for most end-stage lung diseases. Airway com­plications are one of the most important problems during the first year after lung transplant. In this context, the most severe form of bronchial stenosis reported in the literature is vanishing bronchus syndrome, which is the obliteration with atresia of the ostium of a lobar bronchus, usually related to ischemia and infection. Ex vivo lung perfusion is a novel strategy for lung allograft preservation that keeps the organs at physiologic protective conditions. Nevertheless, many ex vivo systems work with lungs in supine position, and upper regions (middle lobe and lingula) can have lower perfusion supply, increasing the risk of a relative ischemia. We report a case of vanishing middle bronchus after ex vivo reconditioning bilateral lung transplant in a 45-year-old man with nonspecific interstitial pneumonia, whose posttransplant course was complicated by Aspergillus fumigatus infection.

Key words : Bronchial stenosis, End-stage lung disease, Pneumonia, Vanishing bronchus syndrome


Lung transplant is often the only treatment option for patients with end-stage lung disease,1 and ex vivo lung perfusion (EVLP) may increase the number of patients treated with lung transplant.2,3 Com­plications due to bronchial anastomosis in lung transplant has remained one of the main reasons for increased morbidity and mortality. These com­plications can occur in up to 27% of patients undergoing lung transplant, with 13% of these patients needing interventional endoscopic treatment. Because bronchial circulation is not reestablished during the transplant procedure, these complications seem to be related to ischemia.4 The literature has reported a strong correlation between the presence of Aspergillus species and airway complications, in particular an increased number of bronchial stenosis.4 The obliteration of a lobar bronchus (either acute or progressive) in lung transplant is called vanishing bronchus syndrome (VBS).5 Two studies have described a low prevalence of VBS in lung transplant recipients.6,7

Case Report

A 45-year-old man with end-stage interstitial lung disease (nonspecific interstitial pneumonia) under­went bilateral lung transplant after EVLP. A chest computed tomography (CT) scan performed on posttransplant day 4 showed a consolidation of the lower left lobe, which resulted in a fiberoptic bronchoscopic examination. Despite normal findings with pervious lobar and segmental bronchi and poor sterile endobronchial secretion, he was empirically treated with vancomycin and ceftazidime. The first follow-up bronchial lung biopsies (performed on posttransplant day 22) documented an acute grade A2 rejection, for which the patient underwent high-dose pulse steroid therapy. On posttransplant day 28, a chest CT scan showed resolution of the consolidation. On posttransplant day 35, the patient underwent a first spirometric evaluation, which revealed forced expiratory volume in 1 second (FEV1) of 1.78 L (50%) and forced vital capacity (FVC) of 2.07 L (47%). The patient was discharged on posttransplant day 49 and was followed as an outpatient.

After discharge, microbiologic sputum analyses remained negative, but spirometric values did not improve. On posttransplant day 90 at the 3-month follow-up, the patient was hospitalized in the pulmonology department. A chest CT scan showed atelectasis of the medium lobe and division of dependent zones. A fibrobronchoscope examination revealed anatomically normal findings, with some purulent secretions (Figure 1). Acute grade A2 rejection was treated by pulse steroid therapy and immunosuppression, with the patient shifted from cyclosporine to tacrolimus. Microbiological cultures were positive for Aspergillus fumigatus complex, and voriconazole therapy was immediately started. Predischarge spirometry revealed FEV1 of 50% and FVC of 49%. After discharge, the patient was asymptomatic and spirometric values were stable.

At the 6-month follow-up after lung transplant, a chest CT scan confirmed complete atelectasis of the middle lobe. At endoscopic control, the lumen of the middle lobe bronchus was obliterated with presence of scar tissue (Figure 2). Biopsies showed minimum acute grade A1 rejection, and spirometric values were stable (FEV1 of 48%, FVC of 52%). A further follow-up visit showed that the middle lobe parenchyma was finally aerated with resolution of atelectasis (probably because of collateral ventilation); however, endoscopy did not show resolution of bronchus obliteration.


Airway complications are one of the most common posttransplant causes of morbidity and death.8 Causes of these complications may depend on both the absence of blood supply to the donor bronchus and on the length of ischemia.9 The following factors may also influence healing of the lower airways: inadequate organ preservation, invasive infection, intensive immunosuppressive therapy, and allograft rejection.8,10

Bronchial stenosis usually appears 1 month after transplant, although it can occur several years later.11 The literature has described 2 patterns of bronchial stenosis: the first involves surgical anastomosis and the second (usually involving intermedius bronchus) involves a nonanastomotic bronchus, resulting in atresia or symptomatic narrowing (also known as VBS).5,12

One of the most difficult tasks during EVLP is keeping the isolated explanted lung edema free to increase the performance of the graft.13 Because many ex vivo systems work with lungs in the supine position, upper regions can have lower perfusion supply, resulting in these regions having an increase in relative ischemia. Moreover, bronchial perfusion is anatomically guaranteed by bronchial arteries, originating from the aorta. During lung transplant, this connection is interrupted and not restored. Both of these facts could partially explain the increased risk of developing stenosis of the intermedius, middle, and lingular bronchus. New approaches of bronchial perfusion have been tested, which have shown encouraging results.14

Cases of association of pretransplant colonization and posttransplant infection by Aspergillus fumigatus and VBS have been reported. Clinicians should be aware of the risk associated with Aspergillus fumigatus and lower airway complications after lung transplant and be ready to promptly begin therapy.5 This is what we did; however, despite antifungal therapy, the patient developed VBS 3 months later.


This is the first case in the literature of VBS after EVLP in bilateral lung transplant. Although bronchial stenosis is a frequent complication after lung transplant, VBS could be a rare evolution. For this reason, prevention with endobronchial stents or dilatation and antimicrobic therapy is still controversial.15


  1. Trulock EP, Christie JD, Edwards LB, et al. Registry of the International Society for Heart and Lung Transplantation: twenty-fourth official adult lung and heart-lung transplantation report-2007. J Heart Lung Transplant. 2007;26(8):782-795.
    CrossRef - PubMed
  2. Cypel M, Yeung JC, Hirayama S, et al. Technique for prolonged normothermic ex vivo lung perfusion. J Heart Lung Transplant. 2008;27(12):1319-1325.
    CrossRef - PubMed
  3. Solidoro P, Patrucco F, Bonato R, et al. Pulmonary hypertension in chronic obstructive pulmonary disease and pulmonary fibrosis: prevalence and hemodynamic differences in lung transplant recipients at transplant center's referral time. Transplant Proc. 2015;47(7):2161-2165.
    CrossRef - PubMed
  4. Samano MN, Minamoto H, Junqueira JJ, et al. Bronchial complications following lung transplantation. Transplant Proc. 2009;41(3):921-926.
    CrossRef - PubMed
  5. Hayes D, Jr., Mansour HM. Vanishing bronchus intermedius syndrome in a pediatric patient with cystic fibrosis after lung transplantation. Pediatr Transplant. 2012;16(8):E333-E337.
    CrossRef - PubMed
  6. Shah SS, Karnak D, Minai O, et al. Symptomatic narrowing or atresia of bronchus intermedius following lung transplantation vanishing bronchus intermedius syndrome (VBIS) (Meeting Abstract). CHEST. 2006;130(4):236S.
    CrossRef - PubMed
  7. Kesavan RB, Haddad T, Lunn W, et al. Vanishing bronchus syndrome (Meeting Abstract). CHEST. 2007;132(4):595B.
    CrossRef - PubMed
  8. Weder W, Inci I, Korom S, et al. Airway complications after lung transplantation: risk factors, prevention and outcome. Eur J Cardiothorac Surg. 2009;35(2):293-298; discussion 298.
    CrossRef - PubMed
  9. Shennib H, Massard G. Airway complications in lung transplantation. Ann Thorac Surg. 1994;57(2):506-511.
    CrossRef - PubMed
  10. Kshettry VR, Kroshus TJ, Hertz MI, Hunter DW, Shumway SJ, Bolman RM, 3rd. Early and late airway complications after lung transplantation: incidence and management. Ann Thorac Surg. 1997;63(6):1576-1583.
    CrossRef - PubMed
  11. Choong CK, Sweet SC, Zoole JB, et al. Bronchial airway anastomotic complications after pediatric lung transplantation: incidence, cause, management, and outcome. J Thorac Cardiovasc Surg. 2006;131(1):198-203.
    CrossRef - PubMed
  12. De Gracia J, Culebras M, Alvarez A, et al. Bronchoscopic balloon dilatation in the management of bronchial stenosis following lung transplantation. Respir Med. 2007;101(1):27-33.
    CrossRef - PubMed
  13. Sanchez PG, Bittle GJ, Burdorf L, Pierson RN, 3rd, Griffith BP. State of art: clinical ex vivo lung perfusion: rationale, current status, and future directions. J Heart Lung Transplant. 2012;31(4):339-348.
    CrossRef - PubMed
  14. Tanaka Y, Inaty H, Machuzak MS. A new lung preservation technique through bronchial artery perfusion on ex-vivo lung. J Heart Lung Transplant. 2013;32(4):S300.
    CrossRef - PubMed
  15. Alraiyes AH, Inaty H, Machuzak MS. Vanishing bronchus after lung transplantation: the role of sequential airway dilatations. Ochsner J. 2017;17(1):71-75.
    CrossRef - PubMed

Volume : 18
Issue : 1
Pages : 133 - 135
DOI : 10.6002/ect.2019.0073

PDF VIEW [959] KB.

From the 1Cardiothoracic and Vascular Department, Division of Respiratory Medicine, “Città della Salute e della Scienza” Hospital and University of Torino, Turin, Italy; the 2Department of Translational Medicine, University of Piemonte Orientale, Novara, Italy; and the 3Cardiothoracic and Vascular Department, Division of Cardiac Surgery, “Città della Salute e della Scienza” Hospital and University of Torino, Turin, Italy
Acknowledgements: The authors declare that no potential conflicts of interest exist with any company/organization whose products or services are discussed in this article. The authors have no sources of funding for this study to declare.
Corresponding author: Filippo Patrucco, Cardiothoracic Department, Division of Respiratory Medicine, “Città della Salute e della Scienza” Hospital and University of Torino, Corso Bramante 88/90, 10126 Turin, Italy
