Objectives: In dogs with deep analgesia caused by acute spinal cord injury from thoracolumbar disk herniation, autologous bone marrow mononuclear cell transplant may improve recovery. The purpose of the present study was to evaluate autologous bone marrow mononuclear cell transplant in a dog that had paraplegia and deep analgesia caused by chronic spinal cord injury.
Materials and Methods: Autologous bone marrow mononuclear cell transplant was performed in a dog having paraplegia and analgesia for 3 years that was caused by a chronic spinal cord injury secondary to Hansen type I thoracolumbar disk herniation. Functional recovery was evaluated with electrophysiologic studies and the Texas Spinal Cord Injury Scale.
Results: Somatosensory evoked potentials were absent before transplant but were detected after transplant. Functional improvement was noted (Texas Spinal Cord Injury Scale: before transplant, 0; after transplant, 6). No adverse events were observed.
Conclusions: Autologous bone marrow mono-nuclear cell transplant into the subarachnoid space may be a safe and beneficial treatment for chronic spinal cord injury in dogs.
Key words : Disk herniation, Diskectomy, Paraplegia, Veterinary medicine
Hansen type I thoracolumbar disk herniation frequently is seen in miniature dachshunds.1 This problem is increasing in frequency because the number of miniature dachshunds has increased in Japan. Surgical intervention is performed for dogs that have paraplegia and analgesia caused by Hansen type I disk herniation. However, recovery after surgery is limited, and dogs without recovery have permanent hind limb paralysis.2
Bone marrow mononuclear cells may have a protective effect on the spinal cord, and an autologous bone marrow mononuclear cell transplant may promote spinal cord regeneration and functional recovery in rats that have spinal cord injury.3 In dogs with deep analgesia caused by an acute spinal cord injury from thoracolumbar disk herniation, an autologous bone marrow mononuclear cell transplant may improve the frequency of recovery compared with surgical intervention without a transplant.2 However, a literature review did not show any previous cases of bone marrow mononuclear cell transplant in dogs with chronic spinal cord injury and long-term analgesia.
In the present study, we performed surgical decompression and autologous bone marrow mononuclear cell transplant in a dog with paraplegia and deep analgesia for 3 years running that was caused by a chronic spinal cord injury secondary to Hansen type I disk herniation. Follow-up evaluation showed improved motor function.
Materials and Methods
A male miniature dachshund (age, 7 y; body weight, 2.9 kg) was diagnosed 3 years ago at another clinic as having paraplegia and analgesia caused by Hansen type I disk herniation. The owner declined surgical treatment because the physician’s opinion that that ambulatory recovery was unlikely. Symptoms did not improve despite nonoperative treatment including acupuncture and rehabilitation.
Evaluation at our clinic, 3 years after the onset of symptoms, showed that the dog appeared healthy, had an appetite, and was in good general condition. Blood test results were normal. The present study was performed in accordance with the Japanese Regulations for Animal Welfare issued by The Ministry of Education, Culture, Sports, Sciences, and Technology of Japan.
Neurologic tests were performed before and after the transplant and included evaluating posture response (proprioception, placing reaction, hopping reaction, and extensor postural thrust), spinal reflexes (patellar, craniotibial, gastrocnemius, flexion, crossed-extension, and panniculus reflexes), presence and absence of pain sensation, and self-micturition.4
Texas Spinal Cord Injury Scale
Improvement of function was evaluated with the Texas Spinal Cord Injury Scale.5 This scale evaluated each pelvic limb separately and had 3 components (gait [range per limb, 0 to 6]; proprioceptive positioning [range per limb, 0 to 2]; and nociceptive response [range per limb, 0 to 2]) that were based on typical clinical neurologic examination techniques for dogs (Table 1). Gait scores for pelvic limbs were based on clinically relevant movement of the limbs. Proprioceptive positioning (also termed “knuckling”) was a postural reaction test. Nociceptive response was assessed by applying a painful stimulus (clamping a hemostat on the distal aspect of the limb or on a nail bed of a digit) and observing the dog for physiologic (tachycardia, tachypnea, and mydriasis) or behavioral responses (orientation toward the stimulus, vocalization, and licking). The total score for each pelvic limb was the sum of the scores for gait, proprioceptive positioning, and nociceptive response (total per limb: range, 0 to 10), and the total score for the dog was the sum of the scores for the 2 pelvic limbs (total: range, 0 to 20) (Table 1).
Somatosensory evoked potentials
Somatosensory evoked potentials were measured with the dog under general anesthesia with isoflurane (Neuropack MEB-9102, Nihon Kohden, Tokyo, Japan). Surface disk electrodes were used as the recording and reference electrodes. The recording electrode was placed at the junction of the coronal and sagittal sutures, and the reference electrode was placed on the spinous process of the second cervical vertebra as previously described.6 Electrical stimulation was applied (frequency, 3 Hz; duration, 0.2 ms).6 The average of 500 responses was determined in each session.
Computed tomography (slice thickness, 1 mm) (Asteion, Toshiba Medical Systems, Tokyo, Japan; Virtual Place Advance Lexus workstation, AZE, Tokyo, Japan) and magnetic resonance imaging scans of spinal cord injury (T1- and T2-weighted images) (0.2-T Vet-MR, ESAOTE S.p.A, Genova, Italy) were performed with the dog under general anesthesia.
Isolation of bone marrow mononuclear cells
Bone marrow mononuclear cells were isolated from a bone marrow aspirate that was collected from the proximal humerus using a bone marrow aspiration needle (16-gauge; 6.83 cm) (Angiotech Pharma-ceuticals, Vancouver, BC, Canada) as previously described.2 Collected bone marrow (5 mL) was mixed with heparinized saline (5 mL; physiologic saline [4 mL] and sodium heparin solution [1 mL]) (Shimizu Pharmaceutical, Shizuoka, Japan). The mixture was subjected to density gradient centrifugation on density gradient medium (density, 1.077 g/mL; volume, 4 mL) (Lymphoprep, Nycomed Pharma, Oslo, Norway) to isolate bone marrow mononuclear cells.
Surgery and bone marrow mononuclear cell transplant
Anesthesia was induced with intravenous propofol (7 mg/kg) (Intervet, Ibaraki, Japan) and maintained with isoflurane (1.5% to 2.0%) (Abbott Laboratories, Abbott Park, IL, USA). Hemilaminectomy was performed to extract protruded disk tissue from the vertebral canal. The extracted disk tissue was evaluated with histology. The bone marrow mononuclear cell suspension (0.2 mL) was injected slowly (duration of injection, 1 min) with an insulin pump (29-gauge) (BD Ultra-Fine, Becton-Dickinson, Fukushima, Japan) into the subarachnoid space at the level of the disk herniation. Preoperative and postoperative pain was treated with once buprenorphine (20 μg/kg) (Otsuka Pharmaceutical, Tokyo, Japan). Cefazolin sodium (25 mg/kg, twice daily for 1 week) (Nichi-Iko Pharmaceutical, Toyama, Japan) was given after surgery.
Analysis of bone marrow mononuclear cells
Cytologic examination of bone marrow mononuclear cells was performed with smear slides of bone marrow mononuclear cell suspension that were prepared before transplant. The smear slides were fixed with methanol and stained with Wright-Giemsa stain (Muto Pure Chemicals, Tokyo, Japan). Cells (1000 cells per slide) were examined and classified according to morphologic characteristics.
There were 1 × 107 cells transplanted. Flow cytometry was performed to analyze bone marrow mononuclear cells obtained from 10 disk herniation cases in the bone marrow mononuclear cell, and surface antigen expression was analyzed. The suspension of bone marrow mononuclear cells in physiologic saline (100 μL; 8.8 × 106 cells/mL) was treated with anti-CD14 antibody that was labeled with fluorescein isothiocyanate (20 μL) (Serotec, Oxford, UK) and anti-CD90 (Serotec), anti-CD4 (Serotec), and anti-CD34 antibodies (BioLegend, San Diego, CA, USA), and the mixture was incubated in the dark at room temperature (30 min). Phosphate buffered saline (900 μL) was added, and the sample was analyzed for cell composition by flow cytometry (counted 100 000 cells each sample) (BD Accuri C6; Becton Dickinson, Franklin Lakes, NJ, USA). Cell viability was determined using the 7-Amino-actinomycin D method.7
Quantitative real-time polymerase chain reaction was performed to analyze cytokines in canine bone marrow mononuclear cells. Reverse transcription of the total RNA (1 μg) was performed (38ºC; 15 min) in reverse transcription reagent (20 μL) (Prime Script RT reagent, Takara, Shiga, Japan). After inactivating the reverse transcription reaction by heating (85ºC; 5 s), the cDNA product was subjected to quantitative real-time polymerase chain reaction (TaqMan Universal Master Mix II and ABI 7500 Real Time PCR system Sequence Detection System, Applied Biosystems, Foster City, CA, USA). A shuttle polymerase chain reaction protocol was used (50ºC for 10 min, then 40 cycles at 95ºC for 15 s, then at 60ºC for 1 min) (reaction volume, 20 μL). The reaction mixture included template cDNA (2 μL), Probs (TaqMan Gene Expression Assays, Applied Biosystems) (interleukin 4 [IL-4], interleukin 10 [IL-10], hepatocyte growth factor, interleukin 6 [IL-6]; 1 μL each) (Applied Biosystems), buffer (Master Mix II, Applied Biosystems) (10 μL), and distilled water (7 μL). Relative gene expression values were calculated with the comparative threshold cycle (ΔΔCt) method using software (Sequence Detection System 1.2 software, Applied Biosystems). This method gave the amount of target gene normalized to an 18S ribosomal RNA and was used to determine the mRNA levels of IL-6. The relative expression levels were calculated using the formula ΔΔ threshold cycle (Ct) = ΔCt target mRNA level - ΔCt IL-6, and the value of relative targeting mRNA expression was determined using the expression 2-ΔΔCt.
A sample from the bone marrow mononuclear cell suspension was cultured on tryptone soya agar (30ºC; 7 d) (Nissui Pharmaceutical, Tokyo, Japan). Performance status and blood testing results (white blood cell count, C-reactive protein) were checked for the presence of adverse events 180, 365, 545, 730, and 1245 days after transplant.
Histologic examination of the excised disk tissue showed irregular hyaline cartilage in the trabeculae and adipose tissue and loose connective tissue between the trabeculae. Dense fibrous tissue was seen around bone, and no cellular dysplasia was detected (Figure 1).
The culture showed no bacterial growth. Cytologic examination of bone marrow mononuclear cells showed a predominance of neutrophils (band and segmented), polychromatic erythroblasts, myelocytes, and metamyelocytes (Table 2). Flow cytometry showed that T cells predominantly were CD14 and CD90 cells (Table 2). Quantitative real-time polymerase chain reaction showed a predominance of mRNA of hepatocyte growth factor and IL-10 (Table 2).
Neurologic testing before transplant showed no hind leg posture responses for proprioception, placing reaction, or hopping reaction; the panniculus reflex was absent at and caudal to the T13-L1 intervertebral space; and pain sensation was absent in both hind legs. At 11 days after transplant, proprioception and placing reaction were improved, but pain sensation was absent in both hind legs at 1245 days after transplant (Table 3). After transplant, the total Texas Spinal Cord Injury Scale score was improved (before transplant, 0; day 11 after transplant, 4; day 37 and day 1245 after transplant, 6) (Table 3). However, at day 1245, the dog was unable to walk independently. Somatosensory evoked potentials were not detected before transplant but waveforms were detected with small amplitude and delayed latency at day 11 after transplant.
A computed tomography scan before surgery showed calcified herniated disk tissue in the vertebral canal centered at the T11-T12 intervertebral space; postoperative computed tomography scan confirmed that the herniated disk tissue had been removed (Figure 2). The T2-weighted magnetic resonance imaging scan after surgery showed signal hyperintensity along 3 vertebral bodies centered at T12 (Figure 3). No adverse events were observed in follow-up examinations at 180, 365, 545, 730, and 1245 days after transplant.
The dog in this report had been diagnosed with paraplegia and analgesia caused by Hansen type I disk herniation at T11-T12. Analgesia is an important prognostic factor in canine disk herniation, and spinal cord function typically does not recover when pain sensation is absent for > 2 weeks.8 No effective curative therapy is available for chronic spinal cord injury. Therefore, neurologic improvement was very unlikely in this dog. The presence of calcification in the herniated disk tissue was evidence that this tissue had been herniated for 3 years (Figure 2).
Somatosensory evoked potentials are signals that are evoked by a stimulus at the peripheral nerve in the extremities and sent to the spinal cord and brain.9 These evoked potentials often are used to evaluate the function of the sensory tract and spinal cord in the diagnosis of neurologic diseases and monitoring of nerve conduction during surgery.7,9 In humans, reduction of the waveform amplitude ≥ 50% is evidence of spinal cord dysfunction.10 Somato-sensory evoked potentials are not detectable in dogs that have paraplegia and analgesia caused by thoracolumbar disk herniation.2 Therefore, absence of somatosensory evoked potentials is indicative of spinal cord injury in dogs. In the present case, somatosensory evoked potentials were not detected before surgery but were detected after surgery. This improvement may have occurred because of decompression of the spinal cord after excision of the herniated disk tissue or functional improvement cause by transplanted bone marrow mononuclear cells. A previous study in a rat spinal cord injury model without dural damage showed that bone marrow mononuclear cell transplant may confer neuroprotection, reduce cavity formation, and facilitate recovery of motor function in the acute phase after spinal cord injury.3
The present bone marrow mononuclear cell preparation had higher levels of hepatocyte growth factor, IL-10, and IL-4, than IL-6 mRNAs (Table 2). Hepatocyte growth factor may inhibit apoptosis, stimulate axonal outgrowth, and facilitate recovery of motor function.11,12 In the present case, hepatocyte growth factor in bone marrow mononuclear cells may have contributed to recovery of motor function. In addition, the CD34+ cells that were present may confer protection against nerve injury, supply several nerve growth factors, and facilitate spinal cord regeneration (Table 2).2,13,14 In humans with chronic spinal cord injury, improved sensory and motor function were noted after bone marrow mononuclear cell transplant in 32.6% patients, and this may have occurred because of CD34+ cells present in the bone marrow mononuclear cell preparations.15
Cell transplant had been performed previously by injection into the injured spinal cord, intravenous injection, and intrathecal implant.16-18 Comparison of intravenous, lumbar puncture, and intracerebro-ventricular routes showed that intravenous transplant was the least efficient method.19 Direct transplant into the injured spinal cord may be significantly more effective in improving neurologic symptoms than intravenous transplant.20 In the present case, we injected the cells into the subarachnoid space near the injured spinal cord, and there were no serious adverse events or abnormal findings evident on magnetic resonance imaging or electrophysiologic examination for 1245 days after transplant.
In conclusion, heterogeneous bone marrow mononuclear cell transplant may have neuropro-tective and neurotrophic effects on the chronically injured spinal cord and may promote recovery of motor function despite prolonged paraplegia and analgesia. In the present case, no adverse events were observed at 1245 days after bone marrow mononuclear cell transplant. Further study may be directed to optimize the procedure by adjusting the frequency of transplant and the number of cells for transplant. Autologous bone marrow mononuclear cell transplant into the subarachnoid space may be useful in treating chronic spinal cord injury in dogs.
Volume : 13
Issue : 1
Pages : 100 - 105
DOI : 10.6002/ect.2013.0237
From the 1Department of Bioartificial Organs, Institute for
Frontier Medical Sciences, Kyoto University, Kyoto; the 2Aikouishida
Animal Hospital, Kanagawa; and the 3Division of Veterinary Surgery,
Nippon Veterinary and Life Science University, Tokyo, Japan
Acknowledgements: We greatly appreciate the staff of Aikou Ishida Animal Hospital who performed the sample collection. Public funds were not used in this work; it was supported through private funds of the Aikou Ishida Animal Hospital. The authors have no conflicts of interest to declare.
Corresponding author: Katsushi Tamura, 1195-4 Takamori Isehara-shi Kanagawa 259-1114 Japan
Phone: +81 463 91 4334
Fax: +81 463 91 4334
Table 1. Texas Spinal Cord Injury Scale
Table 2. Analysis of Bone Marrow Mononuclear Cells That Were Transplanted for Treatment of Chronic Spinal Cord Injury in a Dog
Table 3. Neurologic Tests and Texas Spinal Cord Injury Scale Before and After Transplant of Bone Marrow Mononuclear Cells for Treatment of Chronic Spinal Cord Injury in a Dog
Figure 1. Histology of Excised Tissue From the Intervertebral Disk in a Dog With Chronic Spinal Cord Injury
Figure 2. Computed Tomography Scans Before and After Diskectomy in a Dog With Chronic Spinal Cord Injury
Figure 3. Magnetic Resonance Imaging Scan Before Surgery in a Dog With Chronic Spinal Cord Injury
